Specification
| Diameter (mm) | 215 | 260 | 300 |
| Air Flow (m3/h) | 2 | 3 | 5 |
| Service Area (m2) | 0.4-0.8 | 0.6-0.9 | 0.7-1.0 |
| Bubble Size (mm) | 0.8-2.1 | 0.8-2.1 | 0.8-2.1 |
| Oxygenate Capability (kg/h) | 0.15-0.38 | 0.18-0.48 | 0.25-0.55 |
Aeration System Porous Oxygen Air Tray Sparger EPDM Membrane Micro Bubble Disc Diffuser
Fine bubble Disc Diffuser features a unique split pattern and slit shapes, which can disperse air bubbles in an extremely fine and uniform pattern for high oxygen transfer efficiency. A much highly effective and integrated check value enables the aeration zones to be easily shut down for air-on/air-off applications. The membrane disc diffuser can combines effective design, low installation costs, reliability and high performance in intermittent and continuous aeration processes.
Feature
Epdm can resist heat, light, oxygen, especially ozone. Epdm is essentially non-polarity, polarity solution and chemicalresistant, bibulous is low, it has good insulating properties.
Insoluble in water and any solvent, non-toxic and tasteless, chemical properties stable.
High and low temperature resistant, resistence to most chemical and solvents, the lowest friction coefficient in solid materials.The smallest surface tension in a solid material.
Application
* Municipal wastewater treatment
* Industrial wastewater treatment
* Clean water treatment
* Sludge stabilization
* Wastewater ozone diffusion
* Aeration of fish ponds
* Aeration of streams and lakes
Package
Fine bubble disc diffusers are packed with carton box and pallet.
