HomeDosing DeviceAutomatic Dosing Units Are Used To Water Treatment

Automatic Dosing Units Are Used To Water Treatment

Automatic Dosing Units Are Used To Water Treatment.

The equipment can be customized according to your needs.

Product Parameters:

Model
Item
YTH
500
YTH
1000
YTH
1500
YTH
2000
YTH
3000
YTH
4000
YTH
5000
YTH
6000
Capacity
(L/h)
Curing for an hour 500 1000 1500 2000 3000 4000 5000 6000
Power(kw) 0.94 2.45 2.45 2.62 4.89 4.89 4.89 4.89
PAM dosage(kg/h) 1~5 2~10 3~15 3.5~20 4.5~25
Water inlet(m³/h) 0.3~1.5 0.6~3 0.9~4 1.2~6 2.0~10 2.4~12 2.4~12 2.4~12
Reference Dimension
(mm)
L 1370 2000 2130 2200 2400 2720 2700 2970
B 680 1000 1070 1200 1300 1400 1500 1600
H 1485 1770 1810 1970 2270 2355 2222 2322
L1 1320 1950 2080 2150 2350 2670 2630 2900
B1 720 1040 1110 1245 1340 1440 1550 1650
Powder feed port
(DN)
DN25 DN32 DN32 DN32 DN40 DN40 DN40 DN40
Water inlet port
(DN1)
DN25 DN32 DN32 DN32 DN50 DN50 DN50 DN50
Overflow port
(DN2)
DN32 DN40 DN40 DN40 DN40 DN40 DN40 DN40
Vent port
(DN3)
DN25 DN32 DN32 DN32 DN40 DN40 DN40 DN40
N.W.(kg) 250 400 490 550 700 770 960 1050

  • Product Details

Automatic dosing device is a crucial part of modern water treatment system. It uses automation technology to add various chemical agents to water accurately and continuously to achieve water quality control and treatment goals.



Product Introduction:

This product is an automatic dosing device, which can realize the automatic control of dosing and sewage discharge of circulating water system, which can greatly improve the management level of circulating water system, save chemicals, improve the quality of circulating water and reduce production cost.



Product Superiority:

• High accuracy dosage.

• The infusion rate can be controlled at any time.

• Easy installation and maintenance.

• High safety, high quality materials.

• Simple operation, high reliability.

• A wide variety of accessories.

• Save chemicals and costs, avoid excessive or insufficient manual dosing.

• Can be customized according to requirements



Application Area:

• Water treatment field (the most core and the most extensive application) This is the most widely used and most mature technology in automatic dosing devices.

• Industrial process field In many industrial production processes, it is necessary to control the addition of chemical agents precisely to ensure product quality and process stability.



Company Profile:

Shenghe Environmental Protection Co., Ltd. is headquartered in Yixing City, Jiangsu Province, which is known as the “Hometown of Environmental Protection” and located on the shore of Taihu Lake. The company focuses on the field of environmental protection technology and is committed to the research and development and production of eco-friendly products. Our main products include water treatment equipment such as reverse osmosis devices, sludge dewatering machines, mechanical screens, aerators, automatic dosing systems, as well as electrical control cabinets, fillers, and activated carbon. We not only produce high-quality and stable products but also offer comprehensive after-sales services including equipment installation, commissioning, operation, and maintenance. The mission of Shenghe Environmental Protection is to serve customers and lead the environmental protection industry. Our professional production and operation maintenance team provides you with the best solutions and services.



FAQ:
Q: Can you customize products?
A: Yes, we customize machines according to client requirements.

Q: Where is your factory located?
A: In Yixing City, very close to Shanghai-a 2-hour drive.

Q: Do you provide after-sales service?
A: Yes, our engineers offer technical support.

Q: What’s your warranty period?
A: One year after delivery.

Q: What’s your delivery timeline?
A: Typically within 45 days after advance payment.

Q: How do you package exported products?
A: We usually use preservative-treated wooden crates.

Q: What payment methods do you accept?
A: Typically wire transfers or letters of credit.

Q: What shipping options do you provide?
A: Customers decide the transportation method-air freight, express delivery, or sea freight.
