Product Parameters
| MODEL | φ215mm | φ270mm | φ330mm | |||
| Material | EPDM | silastic | EPDM | silastic | EPDM | silastic |
| Service area | 0.3-0.65 m²/h·pieces |
0.3-0.65 m²/h·pieces |
0.4-0.8 m²/h·pieces |
0.4-0.8 m²/h·pieces |
0.5-1 m²/h·pieces |
0.5-1 m²/h·pieces |
| Number of individual diaphragm holes | approx4000 | approx4000 | approx6500 | approx6500 | approx9500 | approx9500 |
| Bubble diameter | 1-2mm | 1-2mm | 1-2mm | 1-2mm | 1-2mm | 1-2mm |
| Life | >5year | >5year | >5year | >5year | >5year | >5year |
| Work ventilation volume | 1-3m³/h | 1-3m³/h | 2-4m³/h | 2-4m³/h | 4-8m³/h | 4-8m³/h |
| OUR | ≥35% | ≥35% | ≥35% | ≥35% | ≥35% | ≥35% |
| Oxygenation capacity | ≥0.27Kg/h | ≥0.27Kg/h | ≥0.35Kg/h | ≥0.35Kg/h | ≥0.52Kg/h | ≥0.52Kg/h |
| Resistance loss | ≤3500Pa | ≤3500Pa | ≤3500Pa | ≤3500Pa | ≤3500Pa | ≤3500Pa |
| Hardness | 43 ShoreA | |||||
| Tensile strength | 14.6Mpa | |||||
| Elongation at break % | 653% | |||||
| Tear strength | 32.0kN//m | |||||
| Resilience% | ≥40 | |||||
