Aufbau Principle:

The spiral press filter’s core assembly consists of fixed and floating rings stacked in alternating layers, with a central spiral shaft that drives the filtration process. The system features a concentrated section at the front and a dewatering section at the rear. The filter gaps between the fixed and floating rings, along with the spiral shaft’s pitch, progressively narrow from the concentrated to dewatering sections. As the spiral shaft rotates, it not only transports sludge from the concentrated section to the dewatering section but also continuously propels the floating rings to clean the filter gaps, effectively preventing clogging.

Principle of dehydration:

After gravity concentration in the concentration part, the sludge is transported to the dehydration part. In the process of moving forward, with the gradual reduction of filter gap and screw pitch according to the dehydration principle, and under the blocking effect of the back pressure plate, great internal pressure is generated, and the volume is continuously reduced to achieve the purpose of full dehydration.

Applicable widely:

• Suitable for municipal sewage, food, beverage, chemical industry, leather, welding materials, paper making, printing and dyeing, pharmaceutical, coal chemical industry, mineral processing, acid washing and electroplating, underground sludge in mine and other industries.

• It is suitable for the dewatering of high and low concentration sludge. When the low concentration (2000mg/L) sludge is dewatered, there is no need to build a thickening tank and storage tank, which reduces the construction cost, reduces the release of phosphorus and the generation of anaerobic odor.

Not easy to block:
It has the function of self-cleaning. There is no need to clean for preventing the blockage of filter gaps, reducing the amount of water for flushing, and reducing the burden of internal circulation. It is the enemy of oily sludge.

Company Profile:

Shenghe Environmental Protection Co., Ltd. is headquartered in Yixing City, Jiangsu Province, which is known as the “Hometown of Environmental Protection” and located on the shore of Taihu Lake. The company focuses on the field of environmental protection technology and is committed to the research and development and production of eco-friendly products. Our main products include water treatment equipment such as reverse osmosis devices, sludge dewatering machines, mechanical screens, aerators, automatic dosing systems, as well as electrical control cabinets, fillers, and activated carbon. We not only produce high-quality and stable products but also offer comprehensive after-sales services including equipment installation, commissioning, operation, and maintenance. The mission of Shenghe Environmental Protection is to serve customers and lead the environmental protection industry. Our professional production and operation maintenance team provides you with the best solutions and services.

FAQ:

Q: Can you customize products?

A: Yes, we customize machines according to client requirements.

Q: Where is your factory located?

A: In Yixing City, very close to Shanghai-a 2-hour drive.

Q: Do you provide after-sales service?

A: Yes, our engineers offer technical support.

Q: What’s your warranty period?

A: One year after delivery.

Q: What’s your delivery timeline?

A: Typically within 45 days after advance payment.

Q: How do you package exported products?

A: We usually use preservative-treated wooden crates.

Q: What payment methods do you accept?

A: Typically wire transfers or letters of credit.

Q: What shipping options do you provide?

A: Customers decide the transportation method-air freight, express delivery, or sea freight.
