HomeAeratorAquaculture Aeration Tray fine bubble diffuser

Aquaculture Aeration Tray fine bubble diffuser

Fine bubble diffuser parameters:

Drum specifications CSPG67-500 CSPG67-750 CSPG67-1000
Membrane material and life Using imported ethylene propylene diene monomer rubber or silicone rubber, 5-8 years of service life
Thickness of membrane 1.8±0.1mm
Adapt to water depth Within 12 meters
Adapt to the volume 2.5-4.5m3/h 3.5-8.0m3/h 5.0-12.0m3/h
Ideal gas volume 4.0m3/h 6.0m3/h 8.0m3/h
Bubble diameter 1-2mm 1-2mm 1-2mm
service area,service space 0.3-0.8m2/each 0.5-1.5m2/each 0.6-2.2m2/each
Clear water oxygen utilization rate (water depth 3-6 m) 20-38.69%
Ventilation resistance 3.5-6.8KPa

  • Product Details

Our Innovation Advantages:

1. The membrane surface features no visible holes, created using German CNC precision drilling technology. This process delivers three key benefits: superior leak-proof sealing, extended tear resistance, and enhanced surface adhesion.

2. The inner liner’s surface incorporates airflow channels that ensure uniform oxygen distribution while reducing resistance during air release.

3. The membrane is mechanically assembled with the base plate and locking ring through anti-lock threaded connections, ensuring permanent secure attachment.

4. A built-in check valve at the aeration plate’s base effectively resolves long-standing backflow issues.

5. Our micro-porous aerators achieve high oxygen utilization efficiency, minimal resistance, and uniform aeration distribution.





Company Profile:

Yixing Shenghe Environmental Protection Co., Ltd. is headquartered in Yixing City, Jiangsu Province, China, known as the “Hometown of Environmental Protection”. Specializing in environmental technology, we focus on research and production in eco-friendly fields. Our company not only provides high-quality and reliable products but also offers comprehensive after-sales services including equipment installation, commissioning, operation, and maintenance. With globalization advancing, environmental issues have become increasingly severe, making environmental protection a global consensus. Choosing appropriate environmental protection equipment to achieve optimal environmental governance has become a common challenge for many companies. Shenghe was founded with the mission to serve clients and lead environmental protection initiatives. We maintain professional production and operational teams that deliver tailored solutions and services.



FAQ:

(1) Q: Can we customize the size?

A:Yes, we can tailor it to your specifications.

(2) Q:What is the delivery timeline for orders?

A:Customized models typically take 30-45 days to ship.

(3) Q:Do you offer overseas after-sales support?

A:Yes, our professional technicians will visit your company for installation, commissioning, and ongoing maintenance.

(4) Q:How do I place an order?

A:You can contact us via email or phone to get a quote.
